CHIEFTEC SMART TFX 400W 80+Bronze ATX
MPN:
GPF-400P
Brand:
CHIEFTEC
Cable Management:
Non-Modular
€51.79
/ incl. VAT
€42.80
/ excl. VAT
/ incl. VAT
/ excl. VAT
In 2 Business Days
5 in Stock
Product Description
Return Policy
Delivery Information
Have questions?
Expert help just one click away
Contact Us
Product Description
A strong GPF power supply unit in TFX format with the latest ATX 2.3 specification and active PFC that is compatible with Intel as well as with AMD CPUs.
Specifications
General
Certifications
CE, EAC, Federal Communications Commission (FCC), RoHS
Efficiency
85%
Part Number
GPF-400P
Power
Input Frequency
47 - 63 Hz
Input Voltage
100 - 240 V
12V Rail Power
The 12V rail powers the CPU and GPU; it is the most important rating for gaming builds.
336 W
3.3V Rail Power
105 W
5V Rail Power
105 W
5VSB Rail Power
10 W
EPS 4+4-pin Connector
Yes
Input Current
6.3 A
Max 12V Current
0.3 A
Max 3.3V Current
16 A
Max 5V Current
18 A
Max 5VSB Current
2 A
Motherboard Power Connector
20+4 pin ATX
SATA Power Connectors
4
Molex Connectors
2
PFC Type
Active PFC (Power Factor Correction) reduces power waste; Passive is older and less efficient.
Active
Protection Features
OVP (Over-Voltage Protection), UVP (Under-Voltage Protection), OCP (Over-Current Protection), OPP (Over-Power Protection) and SCP (Short-Circuit Protection) protect against voltage spikes, over-current and short circuits.
Over voltage, Overheating, Overload, Short circuit, Under voltage
Total Power Output
400 W
Floppy Drive Power Connector
1
Power Factor
0.9
Processor
Cpu Power Cable Length
35 cm
Cooling
Cooling Type
Active
Fan Size
Larger fans (140 mm vs 120 mm) move more air at lower RPM . quieter operation.
80 mm
Fan Count
1 fan(s)
Compatibility
ATX Standard
2.3
Physical
Depth
175 mm
Height
65 mm
Width
85 mm
Motherboard Cable Length
30 cm
Molex Cable Length
150, 350 mm
PSU Form Factor
ATX: standard. SFX: compact for small form-factor builds.
TFX
SATA Power Cable Length
150, 350 mm
Additional
SKU
47339197
EAN
753263076809
