NET GATEWAY CLOUD MAX/UCG-MAX UBIQUITI
MPN:
UCG-MAX
Brand:
Ubiquiti
€363.70
/ incl. VAT
€300.58
/ excl. VAT
/ incl. VAT
/ excl. VAT
In 2 Business Days
23 in Stock
Short description
Return Policy
Warranty
Delivery Information
Have questions?
Expert help just one click away
Contact Us
Product Description
Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support, 1.5 Gbps IPS routing, and selectable NVR storage.
- Includes full UniFi application suite for device management
- Manages 30+ UniFi devices and 300+ clients
- 1.5 Gbps routing with IDS/IPS
- Multi-WAN load balancing
- 512 GB NVMe SSD storage for NVR
- 0.96 LCM status display
- USB-C powered (adapter included)
Specifications
General
Warranty
12
Certifications
CE/Federal Communications Commission (FCC)/Industry Canada (IC)
Model
UCG-MAX
Installed Processors
How many physical CPUs are installed. Most desktops have 1; workstations and servers can have 2 or more.
1
Operating Humidity
5 - 95 %
Output Current
5 A
Product Model Code
UCG-MAX
QoS Support
Quality of Service prioritises camera stream traffic on the network.
Yes
Reset Button
Yes
Physical
Weight
0.519000
Depth
127.6 mm
Height
30 mm
Width
141.8 mm
Enclosure Material
Polycarbonate (PC)
Colour
White
Net Weight
0.512 kg
Connectivity
Bluetooth
Yes
LAN Ports
4
Processor
Processor Family
The CPU product line (e.g. Intel Core i7, AMD Ryzen 7). Higher tier = better performance.
ARM Cortex
Processor Model
Cortex-A53
Built-in Processor
Yes
Base Clock Speed
Base clock speed (GHz) is the guaranteed sustained frequency the CPU runs at under standard load. It sets the lower bound of performance. Higher base clock helps in software that cannot reach the boost frequency for long (long compilations, sustained simu
1500 MHz
CPU Brand
ARM
Display
Control Display Unit
Yes
Display Type
LCM
LED Indicators
Activity/LAN
Storage
SSD Storage
SSD storage (GB or TB) is the usable space on the solid-state drive. The operating system plus a few games and apps already consumes 200-400 GB. 1 TB is comfortable for general use, 2 TB+ for large game libraries or content creation.
512 GB
Additional
SKU
1421280
EAN
810084697122
Power
AC Adapter Included
Yes
Input Voltage
100 - 240 V
Output Voltage
5 V
Max Power Draw
16.1 W
Features
Cabling Technology
10/100/1000Base-T(X)
Memory
RAM
RAM (Random Access Memory) is the system's working memory where active applications and the operating system live. More RAM means smoother multitasking and bigger files can be edited without swapping to disk. 16 GB is the comfortable minimum for modern sy
3072 MB
Memory Type
Memory type sets the RAM generation. DDR5 is the current standard for Intel 12th-gen+ and AMD AM5; it delivers higher bandwidth and lower voltage than DDR4. DDR4 is still common on older platforms. Memory type must match the motherboard; the slots are phy
DDR4
Battery & Security
Firewall Security
Yes
Networking
Dhcp Server
Yes
Ethernet Data Rates
10/100/1000 Mbit/s
Vlan Support
Yes
Wan Connection
Ethernet (RJ-45)
