NET SWITCH 4PORT POE+ T8504-R/01633-001 AXIS

MPN: 01633-001 Brand: AXIS

€1,468.34 / incl. VAT

€1,213.50 / excl. VAT

This product is currently out of stock. Subscribe to back in stock notification.

Short description

Return Policy

Delivery Information

Have questions? Expert help just one click away Contact Us

Product Description

AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE Gigabit switch. In addition, the switch is equipped with two RJ45 and two SFP data ports that allows for extra devices to be connected. The switch uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series. The ruggedized switch is perfect for challenging environments when mounted inside a surveillance cabinet. It is designed to withstand shock, vibrations and temperatures from -40 °C to 75 °C (-40 °F to 167 °F), making it perfect for high demanding installations such as alongside highways and tunnels.

60 W per port, 240 W power budget; Compliant with High PoE 60 W; Dual DC power redundancy; High availability with Rapid Ring; NEMA TS-2 compliant

Specifications

General

Warranty 60

A 10g Supp No

Certifications EN 55032, EN 55024, FCC, ICES-003, VCCI, RCM AS/NZS CISPR 32, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 IEC 62236-4, IEC/EN/UL 60950-1, IEC 60068-2-6, IEC 60068-2-27, 60068-2-31, NEMA TS-2-2003

HS Code 85176990

Jumbo Frames 9216

Jumbo Frames Support Yes

Operating Humidity 5 - 95 %

Physical

Weight 0.600000

Depth 130 mm

Height 135 mm

Width 62 mm

Mounting Brackets Included Yes

Colour Black

Connectivity

Console Port RJ-45

Fiber Optic Connector SFP

Additional

SKU 1262974

EAN 7331021066199

Power

Dc Input Voltage 54 - 57 V

Power Connector DC-in jack

Power Over Ethernet Poe Power Per Port 60 W

Features

Surge Protection Yes

KVM Type KVM switch class . USB, PS/2, IP/CAT5 (over network), HDMI/DisplayPort. Managed

Battery & Security

Authentication Type RADIUS

Password Protection Yes

Security Protocols HTTPS/SNMP/SNMPv3

Networking

Basic Switching Rj 45 Ethernet Ports Quantity 4

Basic Switching Rj 45 Ethernet Ports Type Gigabit Ethernet (10/100/1000)

Mac Address Table 8000 entries

Networking Standards IEEE 802.1Q/IEEE 802.1x

Power Over Ethernet Poe Yes

Power Over Ethernet Poe Ports Quantity 4

Switching Capacity 16 Gbit/s

Throughput 11.9 Mpps

Total Power Over Ethernet Poe Budget 240 W

Vlan Support Yes
